Deskripsi
Router Wireless Totolink N200RE 300Mbps Mini Design Max Use
N200RE
300Mbps Mini Wireless N Router
- Kecepatan Nirkabel 300Mbps
- Desain Mini, Max Use
- Setup Mudah
- Nikmati IPTV Anda
- Beberapa Jaringan Nirkabel untuk Kontrol Akses
- Keamanan Lanjutan
- Bimbingan orang tua
- IPv6 Siap
Mini is Maxi.
Except the default wireless SSID, you are allowed to add two more Wi-Fi networks for different purpose, such as guest use, staff use or manager use, better access control of wireless network.
SPECIFICATION :Â
| Hardware | |
| Interface | – 2 *10/100Mbps LAN Ports- 1 *10/100Mbps WAN Port |
| Power Supply | -Â DC 9V/0.5A |
| Button | – 1 *RST Button- 1 *WPS Button |
| LED Indicator | -Â 1 *CPU, 1 *Wireless, 1 *WAN, 2 *LAN |
| Antenna | – 2*5dBi Fixed Antennas |
| Dimensions (L x W x H) | – 3.6 x 3.1 x 1.0 in. ( 91 x 80 x 25 mm) |
| Wireless | |||||
| Standards | – IEEE 802.11n, IEEE 802.11g, IEEE 802.11b | ||||
| RF Frequency | – 2.4~2.4835GHz | ||||
| Data Rate | – 802. 11n: Up to 300Mbps- 802.11g: Up to 54Mbps (dynamic) – 802.11b: Up to11Mbps (dynamic) | ||||
| EIRP | – < 20dBm | ||||
| Wireless Security | – 64/128-bit WEP, WPA/WPA2 and WPA-Mixed | ||||
| Reception Sensitivity | – 270M: -61 dBm@10% PER- 135M: -65 dBm@10% PER – 54M: -68 dBm@10% PER – 11M: -85 dBm@8% PER – 6M: -88 dBm@10% PER – 1M: -90 dBm@8% PER | ||||
| Software | |
| Operation Mode | – Gateway Mode- Repeater Mode – AP Mode – WISP Mode |
| Network | – Static DHCP Setting, IPTV |
| WAN Type | – Static IP, DHCP, PPPoE/Russia PPPoE, PPTP/Russia PPTP, L2TP/Russia L2TP |
| Wireless Functions | – Multiple SSID, Access Control, WDS, WPS |
| Schedule | – Reboot Schedule, Wireless Schedule |
| QoS | – QoS Setup, Connect Limit Control |
| Firewall | – MAC Filtering, IP/Port Filtering, URL Filtering, Virtual Server(Port Forwarding) , DMZ |
| System | -Upgrade Firmware, Save/Reload Settings, Time Zone Settings, DDNS, Denial-of-Service, TR-069 Config, Password Settings, System Log, and more |
| Others | |||||
| Package Contents | – N200RE Wireless Router *1- Power Adapter *1 – Ethernet Cable *1 – Quick Installation Guide *1 | ||||
| Environment | - Operating Temperature: 0℃~40 ℃ (32 ℉~104℉)- Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)- Operating Humidity: 10%~90% non-condensing – Storage Humidity: 5%~90% non-condensing | ||||
