Motherboard Intel ECS H110M4-C2H LGA1151 DDR4 2400

Rp10.000

Compare
Ketersediaan: Stok habis
SKU:MB ECS 114

Deskripsi

MB ECS 114 - Copy

Motherboard Intel ECS H110M4-C2H LGA1151 DDR4 2400



Features :
Windows 10 Workable support
Applied 100% Solid capacitor design to maximize component reliability (Optional)
ECS Durathon Technology ensure the stability, reliability and performance of system.
ESD Protection prevents computers from electrostatic discharge damage to enhance
its durability and lifespan
Supports GUI UEFI for tweaking BIOS in Graphical interface within a multi language
environment
Intel® 14nm 6th generation Multi-Core CPU support
Intel® 14nm 7th generation Multi-Core CPU support
Supports DirectX® 12 to enhance graphical performance
Supports HDMI 1.4a Technology ( resolution up to 1920X1200 ) and HDCP function
ECS Intelligent EZ Utility : eBLU, eDLU, eSF

Specification :
CPU
Supports 7th gen Intel® Core™ family/ Pentium / Celeron series processors for LGA 1151 socket
Supports 6th gen Intel® Core™ family/ Pentium / Celeron series processors for LGA 1151 socket
100% Solid capacitor design
Please refer to CPU support list for details
CHIPSET
Intel® H110 Express Chipset
GRAPHICS
Supports DirectX® 12
MEMORY
Dual-channel DDR4 Memory architecture
Supports DDR4 2400 non-ECC, Un-buffered SDRAM Memory
2 X 288-pin DDR4 DIMM socket
Support up to 32 GB*
Note:Please refer to the latest Memory support list for details
EXPANSION SLOT
1 X PCI Express X16 Gen 3.0 slot(s)
1 X PCI Express X 1 Gen 2.0 slot(s)
STORAGE
Support by H110 Express Chipset
4 X Serial ATAIII 6Gb/s
AUDIO
6-Channel HD audio CODEC
Realtek ALC662 6-channel High Definition audio CODEC
LAN
Realtek 8111H Gigabit Fast Ethernet Controller
Wake-On-LAN
USB
Support by H110 Express Chipset
4 X USB 3.2 Gen 1×1 port(s) up to 5Gb/s (either rear I/O or front header)
6 X USB2.0 port(s) Up to 480 Mb/s
REAR PANEL I/O
1 X PS/2 Keyboard & PS/2 mouse connectors
1 X Audio port (Line Out/Line In/Mic In)
1 X RJ-45 port
1 X HDMI port(s)
1 X D-Sub (VGA) port(s)
2 X USB 3.2 Gen 1×1 port(s)
2 X USB2.0 port(s)
CONNECTORS & HEADERS
1 X 24-pin ATX Power Supply connector
1 X 4-pin 12V Power connector
1 X 4-pin CPU_FAN connector
1 X 4-pin SYS_FAN connector
1 X Front Panel switch/LED header
1 X Front panel audio header
1 X USB 3.2 Gen 1×1 header
Support additional 2 USB ports
2 X USB 2.0 header
Support additional 4 USB ports
4 X SATA III 6Gb/s connector(s)
1 X CLR_CMOS header
1 X Serial port header (COM)
SYSTEM BIOS
AMI BIOS with 64 MB SPI Flash ROM
ACPI & DMI
Dual Display
Support GUI UEFI BIOS
Multi-Language BIOS
FORM FACTOR
mATX Form Factor
190mm x 170mm
OS SUPPORT
Windows 7 32-bit
Windows 7 64-bit
Windows 8.1 64-bit
Windows 10 64-bit
* Intel 7th Generation CPUs support Windows 10 64bit only

Informasi Tambahan

Berat 1 Kg
