Motherboard AMD ASRock B450M-HDV R4.0 AM4 DDR4 3200+(OC)

Supports AMD AM4 Socket Ryzenâ„¢ 2000, 3000 and 5000 Series Desktop Processors
2 DIMMs, Supports DDR4 3200+(OC)*
1 PCIe 3.0 x16, 1 PCIe 2.0 x1
Graphics Output : HDMI, DVI-D, D-Sub
7.1 CH HD Audio (Realtek ALC887/897 Audio Codec)
4 SATA3, 1 Ultra M.2 (PCIe Gen3 x4 & SATA3)*
6 USB 3.1 Gen1 (2 Front, 4 Rear)
Realtek Gigabit LAN

SPEC :
Unique Feature :
ASRock Super Alloy
– High Density Glass Fabric PCB
– Sapphire Black PCB
ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)
ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
ASRock Live Update & APP Shop
CPU :
– Supports AMD AM4 Socket Ryzenâ„¢ 2000, 3000 and 5000 Series Desktop Processors
– 6 Power Phase design
– Supports CPU up to 105W
Chipset :
– AMD Promontory B450
Memory :
– Dual Channel DDR4 Memory Technology
– 2 x DDR4 DIMM Slots
– AMD Ryzen series CPUs (Matisse) support DDR4 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory
– AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 3200+(OC) / 2933(OC) / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory
– AMD Ryzen series CPUs (Picasso) support DDR4 2933 / 2667 / 2400 / 2133 non-ECC, un-buffered memory*
– AMD Ryzen series CPUs (Summit Ridge) support DDR4 3200+(OC) / 2933(OC) / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory
– AMD Ryzen series CPUs (Raven Ridge) support DDR4 3200+(OC) / 2933 / 2667 / 2400 / 2133 non-ECC, un-buffered memory
– Max. capacity of system memory: 64GB
– Supports Extreme Memory Profile (XMP) memory modules
– 15μ Gold Contact in DIMM Slots
BIOS :
– 128Mb AMI UEFI Legal BIOS with GUI support
– Supports “Plug and Play”
– ACPI 5.1 compliance wake up events
– Supports jumperfree
– SMBIOS 2.3 support
– DRAM Voltage multi-adjustment
